AIRQUEST All Electric System - Heat Pump & Air Handler
***Installation included***
-
Qualify for rebate?: Yes!
- Suitable for home: Up to 5000 Sqft
- Air Handler Included
- Please note that an electric backup heater is not included.
AIRQUEST by Carrier
DLCURAH R-410A heat pumps.
Energy Efficiency
• 14.7 - 18 SEER2 / 8.2 - 12.4 EER2 / 8.2 - 9.8 HSPF2
Sound
• Levels as low as 54 dBA
Design Features
• Small Footprint
• Integrated 24V and RS-485 communications
Reliability, Quality and Toughness
• Inverter-driven, variable speed, rotary Compressor
• Line lengths up to 213' (65 m)
• Low ambient operation on high heat models down to -22F
(-30C) without the use of wind baffles
• Conventional line set sizes
DLFUAA: Product Data
INDUSTRY LEADING FEATURES / BENEFITS
SECURE OPERATION
If security is an issue, outdoor and indoor units are connected only by
refrigerant piping and wiring to prevent intruders from crawling through
the ductwork. In addition, since outdoor units can be installed close to an
outside wall, coils are protected from vandals and severe weather.
FAST INSTALLATION
This compact ductless system is simple to install. This makes the air
handler systems the equipment of choice, especially in retrofit situations.
On all indoor units, service and maintenance expense is reduced due to
easy accessible service panels. In addition, these air handler systems have
extensive self-diagnostics to assist in troubleshooting.
BUILT-IN RELIABILITY
The air handler system indoor and outdoor units are designed to provide
years of trouble-free operation.
The air handler indoor units include protection against freeze-up and high
evaporator temperatures on heat pumps.
The condensing units on the heat pumps are protected by a three minute
delay that provides over-current protection and high temperature
protection prior to the start of the compressor.
ECONOMICAL OPERATION
The air handler system design allows individual or multi-room heating or
cooling when required. There is no need to run large supply-air fans or
chilled water pumps to handle a few spaces with unique load patterns.
EASY-TO-USE CONTROLS
The air handler units have microprocessor-based controls to provide the
ultimate in comfort and efficiency. The user-friendly control provides the
interface between the user and the unit.
MULTI-POISE INSTALLATION
Designed for maximum installation flexibility. The secondary drain builtin
allows the unit to be mounted in an upflow, downflow, left or right
installation depending on existing conditions.
24V INTERFACE
The built-in 24V Interface allows users to control the system with a third
party thermostat.
AGENCY LISTINGS
All systems are listed with AHRI (Air Conditioning, Heating &
Refrigeration Institute), UL/ETL and CSA.
| Outside model | Air handler unit | Capacity | heating | Rebate | AHRI |
| DLCURAH18ABK | DLFUAAH18XAK | 1.5 | 19000 | $6,500.00 | 209852135 |
| DLCURAH24ABK | DLFUAAH24XAK | 2 | 24000 | $6,500.00 | 209852136 |
| DLCURAH30ABK | DLFUAAH30XAK | 2.5 | 33000 | $6,500.00 | 209852143 |
| DLCURAH36ABK | DLFUAAH36XAK | 3 | 40000 | $6,500.00 | 209852142 |
| DLCURAH48ABK | DLFUAAH48XAK | 4 | 50000 | $6,500.00 | 209852138 |
| DLCURAH60ABK | DLFUAAH60XAK | 5 | 59000 | $6,500.00 | 210025750 |
Documents:
: Airquest DLCURAH Specifications
: AIRQUEST DLFUAA Specifications
: Airquest Performance Series AC Consumer Brochure
: AIRQUEST Split System AC Owners Manual
: Airquest® Residential Condensed Catalog
Warranty:
Parts: 10 Years
Labor: 1 Years
Extend labor warranty 10 years for $700.
The price includes complete installation and warranty and is based on standard installation, however, the price may vary depending on the location and any extra work required such as high voltage wiring, duct modification, crawl space or any other specific installation condition.
This information is general. Contact us for proper heat pump size, talk to an advisor, or request an in-home consultation.
